White rectangular foam rubber gasket 10x50 is a technical foam sealing profile designed for sealing, gap compensation, cushioning, and vibration reduction between two mating surfaces.

With a nominal cross-section of 10x50 mm, the profile is suitable for applications requiring a relatively large contact area and sufficient deformation to compensate for installation tolerances.

Depending on the application, the gasket can be manufactured from closed-cell EPDM foam or Silicone foam.

Specifications of White Foam Rubber Gasket 10x50

When ordering, the dimensional convention should be confirmed. The 10x50 mm dimensions should be referenced against the technical drawing to determine the exact width, height, or thickness.

Closed-Cell Structure of White Foam Rubber 10x50

For closed-cell foam, the material contains small enclosed cells that are separated from one another.

This structure helps the gasket:

• Reduce water penetration through the material.
• Compensate for uneven gaps.
• Provide elastic cushioning.
• Reduce vibration and impact transmission.
• Maintain sealing contact under compression.

This is particularly useful for doors, machine cabinets, equipment housings, and structures requiring protection against dust and water ingress.

However, overall sealing performance also depends on compression, mating-surface condition, joints, and groove design, not only on the foam material itself.

White 10x50 Foam Gasket for Sealing and Gap Compensation

In real-world installation, gaps between two surfaces are rarely perfectly uniform.

A foam gasket can deform under compression and adapt to minor dimensional variations.

It can help to:

• Compensate for gaps.
• Create sealing pressure.
• Reduce open pathways.
• Reduce vibration.
• Reduce impact noise.
• Cushion contacting components.

The 10x50 mm cross-section is particularly useful where a larger contact area or relatively large gap compensation is required.

EPDM Foam or Silicone Foam – Which Should You Choose?

Material selection depends on the operating environment.

White EPDM Foam

EPDM foam is suitable for applications requiring:

• Water resistance.
• Ozone resistance.
• UV resistance.
• Weather resistance.
• Outdoor aging resistance.

It is a practical choice for many doors, frames, and outdoor equipment applications.

White Silicone Foam

Silicone foam is preferred when the application requires:

• Higher temperature resistance.
• Good stability under temperature fluctuations.
• Good aging resistance.
• Stable elasticity within the appropriate temperature range.

For high-temperature applications, the continuous operating temperature and maximum temperature should be specified before selecting the Silicone grade.

How to Select the Correct White 10x50 Foam Gasket

A common mistake is choosing a gasket based only on the nominal gap.

Before ordering, check:

1. Measure the Gap Width

Measure at multiple locations to determine the minimum and maximum gap dimensions.

2. Measure the Closing Distance

For doors and covers, measure the distance between the two surfaces when the assembly is fully closed.

3. Check Gasket Thickness

A gasket that is too thick may:

• Make the door difficult to close.
• Increase compression force.
• Become excessively deformed.

A gasket that is too thin may:

• Provide insufficient sealing pressure.
• Fail to compensate for the gap.
• Leave leakage paths.

4. Determine the Required Compression

The foam gasket should be compressed enough to maintain contact without being excessively compressed over long periods.

Applications of White Rectangular Foam Gasket 10x50

Typical applications include:

• Industrial doors.
• Machine cabinet doors.
• Electrical cabinets.
• Machine housings.
• Equipment frames.
• Industrial machinery.
• Protective panels.
• Storage and industrial doors.
• Metal structures.
• Gap compensation and sealing applications.

Material selection should consider temperature, humidity, UV exposure, compression, and contact environment.

Custom Manufacturing of White 10x50 Foam Gaskets

REP Vietnam can manufacture rectangular foam gaskets according to:

• Custom dimensions.
• Physical samples.
• Technical drawings.
• EPDM foam.
• Silicone foam.
• Required density and hardness.
• Required lengths.
• Small or large quantities.

For production-line applications, important parameters such as profile dimensions, dimensional consistency, and cut length can be controlled according to the agreed specifications.

White Foam Rubber Gasket 10x50 Pricing

Pricing depends on:

• EPDM or Silicone material.
• Foam density.
• Profile dimensions.
• Hardness.
• Required length.
• Order quantity.
• Dimensional tolerances.
• Processing method.

For an accurate quotation, please provide the 10x50 mm specification, required length, quantity, and operating environment.

If an existing gasket sample or technical drawing is available, it should be provided for profile verification.

Supply of White Rectangular Foam Rubber Gasket 10x50

REP VIETNAM JOINT STOCK COMPANY supplies and manufactures white rectangular foam rubber gasket 10x50 for sealing, gap compensation, vibration reduction, and cushioning applications in machinery, doors, and industrial equipment.

Customers can provide:

Sample → dimensions → installation location → temperature → operating environment → quantity

to receive advice on the appropriate foam material and profile.
